Marathon Double Action Diaphragm Bilge Pump 1.5L
Marathon 1.5L double-action diaphragm bilge pump with 58.5 L/min flow, 3 m maximum lift, flexible outlet positions, and spare parts.
Marathon Double Action Diaphragm Bilge Pump 1.5L
Overview
The Marathon Double Action Diaphragm Pump 1.5L is designed for marine bilge pumping applications. Its rugged construction provides resistance to corrosion, electrolysis, and fuel.
The double-action design delivers high-capacity pumping. Its swivelling outlet elbows rotate through 220°, allowing flexible installation in different positions and reducing the required clearance.
The outlet elbows feature threaded connections and O-rings for watertight sealing. A quick-release design also makes installation and handling easier.
Key Features
- Double-Action Design: Provides high-capacity pumping.
- High Flow Rate: Delivers 58.5 L/min at a 1 m head under specified test conditions.
- Marine Application: Resistant to corrosion, electrolysis, and fuel.
- Flexible Installation: Supports multiple mounting positions.
- Swivelling Outlet Elbows: Rotate through 220° for easier installation.
- Watertight Connections: Threaded outlets with O-rings help prevent leakage.
- Spare Parts Available: Replacement diaphragms, valves, handles, covers, and other parts are listed.
Technical Specifications
| Item | Specification |
|---|---|
| Brand | Marathon |
| Product Name | Double Action Diaphragm Pump 1.5L |
| SKU | 11724 |
| Pump Type | Double-Action Diaphragm Pump |
| Flow Rate | 58.5 L/min |
| Maximum Lift | 3 m |
| Hose Diameter | 38 mm |
| Outlet Elbow Rotation | 220° |
| Clearance Range | 290–400 mm maximum |
| Weight | Approximately 1.84 kg (listed article weight: 2 kg) |
| Article Length | 23 cm |
| Article Depth | 37.5 cm |
| Article Height | 20 cm |
| Sales Unit | 1 unit |
Flow test conditions: 45 strokes/min at a 1 m head and 10 kPa pressure, according to ISO 15083. The stated flow tolerance is ±0.05 L.
Available Spare Parts
| Spare Part | SKU |
|---|---|
| Pump Cover | 12611 |
| Spare Handle, 40 cm | 14315 |
| Hose, Diameter 38 mm | 66896 |
| Handle Stowage Clips | 16702 |
| Rear Pump Screw Cap | 18040 |
| Spare Diaphragm | 16217 |
| Inlet/Outlet Valve Set | 16213 |
| Watertight Cover Gasket Complying with IOR Rule | 14263 |
| Straight Outlet Kit, 2 Pieces | 17491 |
| Outlet Elbow Kit, 2 Pieces | 17492 |
Applications
This pump is designed for marine bilge water removal and related onboard pumping applications. Its adjustable outlet positions help accommodate different boat installations.
